PERFORMANCE
MODEL INFORMATION
Model: 83JG00C4PH
Processor: AMD Ryzen™ 7 250 (8C / 16T, 3.3 / 5.1GHz, 8MB L2 / 16MB L3)
AI PC Category: AI-Powered Gaming PC
NPU: Integrated AMD Ryzen™ AI, up to 16 TOPS
Graphics: NVIDIA GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 100W, 572 AI TOPS
Chipset: AMD SoC Platform
Memory: 1x 16GB SODIMM DDR5-5600
Memory Slots: Two DDR5 SODIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-5600 offering
Storage: 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot:
Two M.2 slots • One M.2 2280 PCIe® 4.0 x4 slot • One M.2 2280 PCIe® 4.0 x2 slot
Max Storage Support:
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
Optical: None
Card Reader: No Card Reader
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, optimized with Nahimic Audio
Microphone: 2x, Array
Camera: 5.0MP with E-shutter
Battery: 60Wh
Power Adapter: 170W Slim Tip (3-pin)
Special Features: AI Chip: LA1
DESIGN
Display: 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®
Touchscreen: None
Screen-to-Body Ratio: 88% AAR (active area ratio)
Color Calibration: No Color Calibration
Pen: Pen Not Supported
Keyboard: 24-Zone RGB Backlit, English
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH): 359.86 x 258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
Weight: Starting at 2.4 kg (5.29 lbs)
Case Color: Luna Grey
Case Material: PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment: Painting
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Trial + Lenovo® AI Now
CONNECTIVITY
WLAN + Bluetooth: Wi-Fi® 6, 802.11ax 2x2 + BT5.3
WWAN: WWAN Not Supported
Ethernet: 100/1000M (RJ-45)
Standard Ports:
-
3x USB-A (USB 5Gbps / USB 3.2 Gen 1)
-
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 1.4
-
1x HDMI® 2.1, up to 8K/60Hz
-
1x Headphone / microphone combo jack (3.5mm)
-
1x Ethernet (RJ-45)
-
1x Slim tip Power connector
Docking
Various docking solutions supported via or USB-C®. For more compatible docking solutions, please visit Docking for LOQ™ 15AHP10
SECURITY & PRIVACY
Security Chip: Firmware TPM 2.0 Enabled
Fingerprint Reader: No Fingerprint Reader
Other Security: E-shutter
SERVICE
Base Warranty: 1-year, Courier or Carry-in
Included Upgrade: 2Y Premium Care -IPENTRY (ESS)
ACCESSORIES
Bundled Accessories: None
CERTIFICATIONS
Green Certifications:
-
ErP Lot 6/26
-
RoHS compliant
Other Certifications: TÜV Rheinland® Low Blue Light (Software Solution)
